Description
KEY SYSTEM FEATURES
– Use of stainless steel plate on the guides.
– Design of profiles with straight lines.
– Rubber sealing pad (EPDM) of the guides in superimposed and recessed.
– Possibility of installing double glazing up to 21mm.
– Possibility of placing a single pane of glass up to 5mm.
– Possibility of combination with NOVA 150 for complex constructions.
specifications
– Aluminum alloy: EN AW 6060 T66
– Hardness: 12 Webster
– Minimum paint thickness: 75μm
– Thickness of profiles: 1, 2 mm
– Dimensional tolerances according to: EN DIN 12020-02
– Overhead guide width: 81.4mm (two sheets)
– Recessed guide width: 108.8mm (glass-screen-shutter)
– Sheet dimensions window-shutter length: 28.5mm
– Glass sheet glazing thickness: up to 21mm
– Maximum sheet dimension (WxH): 0.9m x 2.2m
– Maximum sheet weight: 80 Kgr
BUILDING TYPES
– Overlapping
– Sinkers
– Composite Constructions
